2025-12-20
This entry marks the first major checkpoint for Revision A of the Nodifyr ESP32-S3 development board.
The goal of this revision is to establish a starting point for continued development with the ESP32-S3 chip.
Current Status
Completed
- Core power architecture:
- USB-C 5 V input
- Single-cell Li-Po support
- 3.3 V regulation for system power
- ESP32-S3-WROOM-N16R2 selected:
- I chose this for its flash/RAM headroom (I figured I would want it to have a lot of flash since it's Nodifyr's first dev board)
- Base MCU supporting circuitry completed
- Boot configuration
- Reset / enable
- Decoupling and bulk capacitance
- USB-C port fully wired on schematic for 5v RECIEVING (5.1kΩ on each CC line)
- Bill of Materials (BOM) populated
- Manufacturer part numbers (MPNs)
- LCSC part numbers for assembly
- Altium project structure established and committed
The nodifyr-hardware repository currently contains:
- Altium Designer 26 project file
- Schematic document
- BOM document
- Integrated libraries (IntLib) for parts not available via the Altium Content Vault
- Exported schematic PDF
Not Yet Included
- PCB document (no layout has begun)
- Output job files (dependent on PCB creation)
The design is still in an architectural phase.
Design Decisions So Far
-
ESP32-S3 over ESP32-C3 The S3 was selected despite higher compute capability than strictly required. The additional GPIO, RAM, and flash provide breathing room for:
-
accessory experimentation
- future firmware features
-
board reuse
-
Assembly-aware BOM from day one
All components are selected with real assembly in mind (LCSC/JLCPCB part #'s and confirmed stock).
TODOs
- Finalize GPIO allocation and pin mapping
- Define and standardize external connectors
- screw terminals
- waterproof multi-pin connectors
- Decide on:
- debug header strategy
- expansion interfaces
- Begin PCB layout once schematic stabilizes
- Add board bring-up and test planning docs
